Close Coupled Centrifugal Pumps with Threaded Ports

NM, NMD Series

Flow

1 - 66

m³/h

Head

3.5 - 114

m

Power

0.37 - 9.2

kW

Flow

4.40-290

usgpm

Head

11-374

ft

Power

0.49-12.33

hp

Applications

- For clean liquids without abrasives, which are non-aggressive for the pump materials (solids content up to 0.2%).

- For water supply.

- For heating, air-conditioning, cooling and circulation plants.

- For civil and industrial applications.

- For fire fighting applications.

- For irrigation.

Construction

Close-coupled, centrifugal pumps; electric motor with extended shaft directly connected to the pump.

NM: single-impeller.

NMD: with two back-to-back impellers (with axial thrust balancing).

Catalog

60 Hz Catalogue

Download (525.99 KB)
